Features
• Controlled by micro-computer;128×64-pixel big size LCD display
• LCD display can show the output information, voltage, current, power and timer can be shown at the same time
• Alarm function of over-voltage, over-current, overload and no-load etc.
• With the function of program memory:9 steps program (1-9).
• Constant voltage, constant current, constant power with automatic cross-over and shows which parameter keeps constant.
• Output terminal:2 pairs in parallel.
• With the protection function of short circuit, leakage, overheating
Specifications
• Voltage range:(20-10000) V; (Display Accuracy:10V)
• Current range:(0-3000) μA; (Display Accuracy:1μA)
• Power range:30W
• Dimension(W×D×H):245mm×325mm×104mm
• Net weight: about 3.2KG
Application: Applied to isoelectric focusing in the system of two-dimensional electrophoresis
