Product Description:
l It applies the internationally advanced digital control circuit, which ensures stable and accurate speed. It uses large-power frequency motor power, which ensures a long service life. Using Taikang compressors made in France, its temperature can be freely set with high precision of temperature control and little noise.
l Using touch panel, LCD and Chinese operation software and control keys, it is easy to operate.
l Its procedures can be programmed, saved and used. Users can set nine procedures for daily operation; 0-8 degree up / down rate, allowing users to flexibly choose proper centrifugal process to achieve the best effect and RCF value is automatically calculated.
l It has a lot of security measures, such as stainless steel centrifugal chamber, safe locks, over-speed protection, over-temperature protection, unbalance protection and fault diagnosis, etc. which ensures human and machine security.
Technical Parameters:
|
Model |
SE-CF-GL12M |
|
Max. Speed |
12000r/min |
|
Max. RCF |
19950×g |
|
Max Capacity |
6×1000ml |
|
No1 Angle Rotor |
8×100ml (12000r/min RCF 19950×g) |
|
No2 Angle Rotor |
6×500ml (10000r/min RCF 17000×g) |
|
No3 Angle Rotor |
6×1000ml (7000r/min RCF 11500×g) |
|
Speed accuracy |
±20r/min |
|
Temp Range |
-20℃－40℃ |
|
Temp Accuracy |
±1℃ |
|
Time Range |
0-23h59min |
|
Ac/Dc Rate |
0-8 degree |
|
Control and Driver |
Frequency conversion motor, crisis control, direct-drive |
|
Daily-use Program |
9 |
|
Refrigerator Power |
2kw |
|
Noise |
≤65Db |
|
Power |
Ac220V 50Hz 30A |
|
Weight (excluding rotors) |
220Kg |
|
Dimensions |
680×780×1220mm（L×W×H） |
|
Product Model & Name |
Max (r/min) |
Max. Capacity (ml) |
Max. RCF |
Comments |
|
SE-CF-GL12M |
12000 |
/ |
19950 ×g |
Host |
|
No.1Angle Rotor |
12000 |
8×100ml |
19950 ×g |
Optional |
|
No.2Angle Rotor |
10000 |
6×500ml |
17000×g |
Optional |
|
No.3Angle Rotor |
7000 |
6×1000ml |
11500×g |
Optional |
