Features：
★Integrated with incubator and shaker to save space and cost.
★High quality steel shell, polished stainless-steel chamber.
★Unique slope design panel with large LCD display, better visual effect.
★With operation data memory and password locking function to eliminate faulty operation.
★ Non-volatile memory saves settings during a power outage and automatically restarts the unit as originally programmed after power is restored.
★When the measured temperature deviates from set temperature by 3℃(can be set arbitrarily) will automatically stop heating and send out audible and visual alarms.
★LYZ-2102C, LYZ-2102, LYZ-2112B equips with strong and fast refrigeration system for instant cooling requirements, automatic defrost.
★The most advanced large torque motor to ensure continuous work without maintenance.
★With large view window and built-in lighting for easy observation.
★ Low noise, luxury and beautiful appearance.
★ Equipped with leakage protection.
Options:
1.Universal Tray
2.Stainless steel flask clamp (50ml,100ml,250ml,500ml,1000ml,2000ml,3000ml,5000ml available)
Specifications
|
Model |
LYZ-2102C (Single door) |
LYZ-1102C (Single door) |
LYZ-2102 (Double door) |
LYZ-1102 (Double door) |
LYZ-2112B (Double door) |
LYZ-1112B (Double door) |
|
|
Shaking Speed(rpm) |
40-300 |
||||||
|
Speed Accuracy(rpm) |
±1 |
||||||
|
Swing Amplitude(mm) |
Φ26 |
||||||
|
Standard Configuration |
250ml×24 |
250ml×35 or 500ml×24 |
250ml×45 or 500×37 |
||||
|
Maximum Capacity |
100ml×48 or 250ml×24 or 500ml×18 or 1000ml×12 |
250ml×70 or 500ml×48or 1000ml×24 or 2000ml×8 |
250ml×90 or 500ml×74or 1000ml×36 or 5000ml×8 |
||||
|
Tray Size (mm |
500×350 |
740×460 |
970×760 |
||||
|
Power Rating(W) |
550 |
380 |
750 |
550 |
1420 |
1150 |
|
|
Temperature Range( ℃) |
4-60 |
RT+5-60 |
4-60 |
RT+5-60 |
4-60 |
RT+5-60 |
|
|
Temperature Accuracy ( ℃) |
±0.1 |
||||||
|
Temperature Uniformity( ℃)) |
±1 |
||||||
|
Timing Range |
1-9999min |
||||||
|
Display |
LCD |
||||||
|
Power Supply |
AC220V～240V±10% , 50～60HZ |
||||||
|
Tray Included |
2 |
||||||
|
Volume W×D×H(mm) |
66×44×65(170L) |
84×52×64(280L) |
109.5×62.5×85(582L) |
||||
|
Exterior Size(W×D×H) mm |
70×56×126 |
95×70×126 |
120×82×160 |
||||
|
Net Weight(kg) |
165 |
140 |
240 |
220 |
425 |
456 |
|
